Quickstart

Quick Start: Your First Agent

Summary: Build a working voice AI agent in under 5 minutes with a single Python file.

The Minimal Agent

#!/usr/bin/env python3
## my_first_agent.py - A simple voice AI agent
"""
My First SignalWire Agent

A simple voice AI agent that greets callers and has conversations.
"""

from signalwire_agents import AgentBase


class MyFirstAgent(AgentBase):
    def __init__(self):
        super().__init__(name="my-first-agent")

        # Set the voice
        self.add_language("English", "en-US", "rime.spore")

        # Define the AI's personality and behavior
        self.prompt_add_section(
            "Role",
            "You are a friendly and helpful assistant. Greet the caller warmly "
            "and help them with any questions they have. Keep responses concise "
            "and conversational."
        )

        self.prompt_add_section(
            "Guidelines",
            body="Follow these rules:",
            bullets=[
                "Be friendly and professional",
                "Keep responses brief (1-2 sentences when possible)",
                "If you don't know something, say so honestly",
                "End conversations politely when the caller is done"
            ]
        )


if __name__ == "__main__":
    agent = MyFirstAgent()
    print("Starting My First Agent...")
    print("Server running at: http://localhost:3000")
    print("Press Ctrl+C to stop")
    agent.run()

Run the Agent

Start your agent:

python my_first_agent.py

You'll see output like:

[12:29:56] INFO     security_config (info:72) security_config_loaded
    (service=SWMLService, ssl_enabled=False, domain=None,
    allowed_hosts=['*'], cors_origins=['*'], max_request_size=10485760,
    rate_limit=60, use_hsts=True, has_basic_auth=False)
[12:29:56] INFO     swml_service    (info:72) service_initializing
    (service=my-first-agent, route=, host=0.0.0.0, port=3000)
[12:29:56] INFO     agent_base      (info:72) agent_initializing
    (agent=my-first-agent, route=/, host=0.0.0.0, port=3000)
Starting My First Agent...
Server running at: http://localhost:3000
Press Ctrl+C to stop
[12:29:56] INFO     agent_base      (info:72) agent_starting
    (agent=my-first-agent, url=http://localhost:3000, username=signalwire,
    password_length=43, auth_source=provided, ssl_enabled=False)
Agent 'my-first-agent' is available at:
URL: http://localhost:3000
Basic Auth: signalwire:7vVZ8iMTOWL0Y7-BG6xaN3qhjmcm4Sf59nORNdlF9bs
    (source: provided)
INFO:     Started server process [49982]
INFO:     Waiting for application startup.
INFO:     Application startup complete.
INFO:     Uvicorn running on http://0.0.0.0:3000 (Press CTRL+C to quit)

Note: The SDK shows:

• Security configuration (SSL, CORS, rate limits)
• Service initialization details
• Basic auth credentials (username and password)
• Server startup information

Test the Agent

Open a new terminal and test with curl. Use the Basic Auth credentials shown in the agent output:

## Get the SWML document (what SignalWire receives)
## Replace the password with the one from your agent's output
curl -u signalwire:7vVZ8iMTOWL0Y7-BG6xaN3qhjmcm4Sf59nORNdlF9bs \
  http://localhost:3000/

Note: The -u flag provides Basic Auth credentials in the format username:password. Use the exact password shown in your agent's startup output.

You'll see JSON output like:

{
  "version": "1.0.0",
  "sections": {
    "main": [
      {"answer": {}},
      {
        "ai": {
          "prompt": {
            "text": "# Role\nYou are a friendly and helpful assistant..."
          },
          "languages": [
            {"name": "English", "code": "en-US", "voice": "rime.spore"}
          ]
        }
      }
    ]
  }
}

What Just Happened?

1. You run: python my_first_agent.py

Agent starts a web server on port 3000.

2. SignalWire (or curl) sends: GET http://localhost:3000/

Agent returns SWML document (JSON).

3. SWML tells SignalWire:

• Answer the call
• Use this AI prompt (your personality config)
• Use this voice (rime.spore)
• Use English language

4. SignalWire's AI:

• Converts caller's speech to text (STT)
• Sends text to AI model (GPT-4, etc.)
• Gets AI response
• Converts response to speech (TTS)

Adding a Custom Function

Let's add a function the AI can call:

#!/usr/bin/env python3
## my_first_agent_with_function.py - Agent with custom function
"""
My First SignalWire Agent - With Custom Function
"""

from signalwire_agents import AgentBase, SwaigFunctionResult


class MyFirstAgent(AgentBase):
    def __init__(self):
        super().__init__(name="my-first-agent")

        # Set the voice
        self.add_language("English", "en-US", "rime.spore")

        # Define the AI's personality
        self.prompt_add_section(
            "Role",
            "You are a friendly assistant who can tell jokes. "
            "When someone asks for a joke, use your tell_joke function."
        )

        # Register the custom function
        self.define_tool(
            name="tell_joke",
            description="Tell a joke to the caller",
            parameters={"type": "object", "properties": {}},
            handler=self.tell_joke
        )

    def tell_joke(self, args, raw_data):
        """Return a joke for the AI to tell."""
        import random
        jokes = [
            "Why do programmers prefer dark mode? Because light attracts bugs!",
            "Why did the Python programmer need glasses? Because they couldn't C!",
            "What's a programmer's favorite hangout spot? Foo Bar!",
        ]
        joke = random.choice(jokes)
        return SwaigFunctionResult(f"Here's a joke: {joke}")


if __name__ == "__main__":
    agent = MyFirstAgent()
    print("Starting My First Agent (with jokes!)...")
    print("Server running at: http://localhost:3000")
    agent.run()

Now when a caller asks for a joke, the AI will call your tell_joke function!

Using the Debug Endpoint

The agent provides a debug endpoint to inspect its configuration:

curl http://localhost:3000/debug

This shows detailed information about:

• Registered functions
• Prompt configuration
• Voice settings
• Authentication credentials

Test with swaig-test CLI

The SDK includes a CLI tool for testing:

## Show the SWML document
swaig-test my_first_agent.py --dump-swml

## List available functions
swaig-test my_first_agent.py --list-tools

## Test a function
swaig-test my_first_agent.py --exec tell_joke

Complete Example with Multiple Features

Here's a more complete example showing common patterns:

#!/usr/bin/env python3
## complete_first_agent.py - Complete agent example with multiple features
"""
Complete First Agent Example

Demonstrates:

- Voice configuration
- AI parameters
- Prompt sections
- Custom functions
- Speech hints
"""

from signalwire_agents import AgentBase, SwaigFunctionResult


class CompleteFirstAgent(AgentBase):
    def __init__(self):
        super().__init__(
            name="complete-agent",
            auto_answer=True,
            record_call=False
        )

        # Voice and language
        self.add_language("English", "en-US", "rime.spore")

        # AI behavior parameters
        self.set_params({
            "end_of_speech_timeout": 500,      # Wait 500ms for speaker to finish
            "attention_timeout": 15000         # 15 second attention span
        })

        # Speech recognition hints (improves accuracy)
        self.add_hints([
            "SignalWire",
            "SWML",
            "AI agent"
        ])

        # Prompt sections
        self.prompt_add_section(
            "Identity",
            "You are Alex, a helpful AI assistant created by SignalWire."
        )

        self.prompt_add_section(
            "Capabilities",
            body="You can help callers with:",
            bullets=[
                "Answering general questions",
                "Telling jokes",
                "Providing the current time",
                "Basic conversation"
            ]
        )

        self.prompt_add_section(
            "Style",
            "Keep responses brief and friendly. Use a conversational tone."
        )

        # Register functions
        self.define_tool(
            name="get_current_time",
            description="Get the current time",
            parameters={"type": "object", "properties": {}},
            handler=self.get_current_time
        )

        self.define_tool(
            name="tell_joke",
            description="Tell a random joke",
            parameters={"type": "object", "properties": {}},
            handler=self.tell_joke
        )

    def get_current_time(self, args, raw_data):
        """Return the current time."""
        from datetime import datetime
        now = datetime.now()
        return SwaigFunctionResult(f"The current time is {now.strftime('%I:%M %p')}")

    def tell_joke(self, args, raw_data):
        """Return a random joke."""
        import random
        jokes = [
            "Why do programmers prefer dark mode? Because light attracts bugs!",
            "Why did the developer go broke? Because they used up all their cache!",
            "There are only 10 types of people: those who understand binary and those who don't.",
        ]
        return SwaigFunctionResult(random.choice(jokes))


if __name__ == "__main__":
    agent = CompleteFirstAgent()

    print("="*60)
    print("Complete First Agent")
    print("="*60)
    print(f"Server: http://localhost:3000")
    print(f"Debug:  http://localhost:3000/debug")
    print("")
    print("Features:")
    print("  - Custom voice (rime.spore)")
    print("  - Speech hints for better recognition")
    print("  - Two custom functions (time, jokes)")
    print("="*60)

    agent.run()

Next Steps

Your agent is running locally, but SignalWire can't reach localhost. You need to expose it to the internet.

Continue to:

1. Development Environment - Set up a professional project structure with environment variables and testing
2. Exposing Your Agent - Make your agent accessible via ngrok so SignalWire can reach it

Or jump ahead to:

• Core Concepts - Understand SWML, SWAIG, and the request lifecycle
• Building Agents - Learn all agent configuration options
